Cabinet Lock Size Guide

Door & Drawer Lock Sizing Tool

Measure the cabinet door or drawer thickness where the lock passes through.

1) Select units

2) Select application

3) What level of security is required?

4) Enter DOOR thickness (inches)

Fractions, mixed fractions, or decimals accepted

Quick pick:

5) Select Finish

Finish options shown are based on the selected lock type.

6) Select Keying Path

7) Select Keying Option

Stock KA #

Results

Part Number

953-14A-C346A

Item: 953 | Finish: 14A | Keying: C346A

Recommended Lock

953

Lock Type

Cam Lock

Cylinder Length

1-3/16"

Maximum Door Thickness Supported

7/8"

(22.2 mm)

Next size up (optional)

955 – Cam Lock, 1-7/16" cylinder, fits up to 1-1/8"
